09180-03972 TIMER ASSY, AUTOMA Denso Cross


Rating:
32
Buy TIMER ASSY, AUTOMA 09180-03972 genuine, new aftermarket engine parts with delivery

Information timer assy, automa Denso

Scheme #.#:

Qty
Part num
Name
Remarks
Manufacture num
000
[01]
09180-03972
TIMER ASSY, AUTOMA
SA2
S2251-02890 HINO
001
[01]
HUB, TIMER
S2251-62080-A HINO
002
[02]
WEIGHT SUB-ASSY, T
S2251-44090-A HINO
003
[02]
CAM, TIMER
S2254-51430-A HINO
004
[02]
CAM, TIMER
S2254-51440-A HINO
005
[04]
WASHER, SNAP
ID6.4
S2251-81110-A HINO
006
[01]
FLANGE, TIMER DRIV
S2251-32680-A HINO
006-001
[01]
SEAL, OIL
ID33.6
S2282-71680-A HINO
007
[4C]
SPRING, TIMER
K0.2 -9710
22515-6990A HINO
007
[4C]
SPRING, TIMER
K0.2,YELLOW -9710
S2251-56830-A HINO
007
[04]
SPRING, TIMER
K0.2,YELLOW 9710-
S2251-56830-A HINO
008
[4C]
SPRING, TIMER SUB
K0.5
S2251-56810-A HINO
008
[4C]
SPRING, TIMER SUB
K0.6,BLUE
S2251-56820-A HINO
009
[8C]
WASHER, PLATE, SK
T0.5
S2288-55870-A HINO
009
[8C]
WASHER, PLATE, SK
T0.6
S2288-55880-A HINO
009
[8C]
WASHER, PLATE, SK
T0.7
S2288-55890-A HINO
009
[8C]
WASHER, PLATE, SK
T0.8
S2288-57340-A HINO
009
[8C]
WASHER, PLATE, SK
T0.9
S2288-57350-A HINO
011
[01]
O-RING
ID120
S2281-71970-A HINO
012
[02]
SUPPORT, TIMER SPR
S2253-51140-A HINO
013
[01]
COVER SUB-ASSY, TI
-0505
22867-1830A HINO
013
[01]
COVER SUB-ASSY, TI
0506-
S2250-11380-A HINO
013-001
[01]
SEAL, OIL
ID36.6
S2282-71690-A HINO
014
[01]
PLATE, TIMER DRIVI
S2251-32690-A HINO
015
[04]
SEAT
S2251-71510-A HINO
016
[02]
ROLLER, TIMER
S2252-21100-A HINO
017
[02]
WASHER, COPPER PLA
T1,ID8.2
S2286-71500-A HINO
018
[02]
SCREW, TIMER HUB
M8
S2286-51270-A HINO
019
[04]
SEAT
S2251-71850-A HINO

Cross reference number



Part num
Firm num
Firm
Name
09180-03972
S2251-0289
TIMER ASSY, AUTOMA
