Information pump assy, supply Denso
Product
Fuel Injection Pump
Vehicle engine
NAVARA YD2K2
Engine
YD2K2
Serial start-end
0610--0801
Info
SM294000-0530, Nissan P/N 16700-EB70A
Injector Nozzle
NISSAN MOTOR
PUMP ASSY, SUPPLY
IA
- SIAM DENSO PRODUCTION SM294000-053#.
Include in ##:
Cross reference number
Part num
Firm num
Firm
Name
SM294-00005
NISSAN MOTOR
PUMP ASSY, SUPPLY
Information:
POSITIONING PIN BEARING
MARKS FOR TIGHTENING CONNECTING ROD BOLTS(1) Bore in connecting rod for piston pin bearing ... 2.1825 .0005 in.(55.436 0.013 mm) Tight fit between connecting rod eye and piston pin bearing ... .002 to .004 in.(0.05 to 0.10 mm) Connecting rod must be heated for installation of piston pin bearing. Do not use a torch.Heat connecting rod to temperature of ... 350 to 500° F (177 to 260° C) Piston pin bearing junction must be assembled within either area "A" (90 10° from the centerline through the connecting rod bores) as shown.(2) Bore in connecting rod for bearing with nuts tight to specifications (6) ... 4.0748 .0005 in.(103.500 0.013 mm)(3) Distance between center of bearings ... 10.300 .002 in.(261.62 0.05 mm)(4) Bore in bearing for piston pin (new) ... 2.0012 .0003 in.(50.830 0.008 mm) Diameter of piston pin (new) ... 1.9998 .0002 in.(50.795 0.005
