Information pump assy, injecti Denso
Product
Fuel Injection Pump
Vehicle engine
COASTER 14B
Engine
14B
Serial start-end
9704-
Info
Injector Nozzle
093500-4060
Manufacture:
22100-5C470 TOYOTA
Dim 1
3.2-3.4
Dim 2
5.8-6.0
Dim 3
7.0-7.2
Dim 4
Dim 5
Dim 6
Information
Injector nozzle:
0935004060
KIT List:
Part name
Kit1
Kit2
Cross reference number
Part num
Firm num
Firm
Name
1960002070
22100-5C470
TOYOTA
PUMP ASSY, INJECTI
Information:
Rotation as seen from the drive end ... clockwiseMinimum (no load) speed (rpm) ... 6500Current consumption (draw) at 20V (no load) ... 77A(1) Torque for the housing bolts ... 11 N m (8 lb ft)(2) Torque for the terminal nuts ... 27 to 34 N m (20 to 25 lb ft)(3) Clearance between the pinion and housing ... 0.51 to 1.27 mm (.020 to .050 in)Used with solenoid ... 3T86353T6305 24V
Rotation as seen from the drive end ... clockwiseMaximum (no load) speed (rpm) ... 5500Maximum current consumption (draw) (no load) ... 200A(1) Torque for the large terminal nuts ... 27 to 33 N m (20 to 24 lb ft) Torque for the small terminal nuts ... 4 to 5 N m (35 to 45 lb in)(2) Service limit of brushes ... 17.5 mm (.69 in)(3) Service limit of commutater diameter ... 48 mm (1.9 in)Pinion to ring gear clearance ... 1.5 to 5.5 mm (.06 to .22 in)Used with solenoid ... 9X03329X4447 24V
(1) Torque for terminal nuts: Small terminal nuts ... 2.25 .25 N m (20 2 lb ft)Large terminal nuts ... 30.5 3.5 N m (22.5 2.5 lb ft)No load conditions: Speed (rpm) ... 3300Current amps ... 80AVoltage ... 23.5Used with solenoid ... 3E0135
Rotation as seen from the drive end ... clockwiseMaximum (no load) speed (rpm) ... 5500Maximum current consumption (draw) (no load) ... 200A(1) Torque for the large terminal nuts ... 27 to 33 N m (20 to 24 lb ft) Torque for the small terminal nuts ... 4 to 5 N m (35 to 45 lb in)(2) Service limit of brushes ... 17.5 mm (.69 in)(3) Service limit of commutater diameter ... 48 mm (1.9 in)Pinion to ring gear clearance ... 1.5 to 5.5 mm (.06 to .22 in)Used with solenoid ... 9X03329X4447 24V
(1) Torque for terminal nuts: Small terminal nuts ... 2.25 .25 N m (20 2 lb ft)Large terminal nuts ... 30.5 3.5 N m (22.5 2.5 lb ft)No load conditions: Speed (rpm) ... 3300Current amps ... 80AVoltage ... 23.5Used with solenoid ... 3E0135
