Information pump assy, injecti Denso
Product
Fuel Injection Pump
Vehicle engine
DYNA 15B-F
Engine
15B-F
Serial start-end
9505--9905
Info
Injector Nozzle
093500-6230
Manufacture:
22100-5C110 TOYOTA
Dim 1
3.4-3.6
Dim 2
7.0-7.2
Dim 3
0.45-0.55
Dim 4
Dim 5
Dim 6
Information
TOYOTA
PUMP ASSY, INJECTI
AA
- *1: THE ORIFICE DIAMETER:096360-0260:1.37,-0270:1.57,
- -280:1.77,-0290:1.97. CHOOSE NO.132 DEPENDING ON THE
- TIMER STROKE VALUE. IF LESS THAN THE STANDARD :USE THE
- SMALLER ORIFICE DIAMETER.IF LARGER:USE THE LARGER ONE.
- MORE THAN 2.4 : 096360-0290.
Injector nozzle:
0935006230
KIT List:
Part name
Kit1
Kit2
Cross reference number
Part num
Firm num
Firm
Name
19600-00050
TOYOTA
PUMP ASSY, INJECTI
1960000050
22100-5C110
TOYOTA
PUMP ASSY, INJECTI
