Information pump assy, injecti Denso
Product
Fuel Injection Pump
Vehicle engine
TRUCK EK100
Engine
EK100
Serial start-end
8511--9002
Info
Injector Nozzle
093500-2690
Injector nozzle:
0935002690
KIT List:
Part name
Kit1
Kit2
Components :
Scheme #.#:
№
Qty
Part num
Name
Remarks
Manufacture num
000
[01]
19100-01660
PUMP ASSY, INJECTI
P6,R722
22010-4530
HINO
Include in ##:
19100-01660
as PUMP ASSY, INJECTI
Cross reference number
Part num
Firm num
Firm
Name
19100-01660
22010-4530
PUMP ASSY, INJECTI
1910001660
22010-4530
HINO
PUMP ASSY, INJECTI
Information:
Introduction
The problem that is identified below does not have a known permanent solution. Until a permanent solution is known, use the solution that is identified below.Problem
If the engine is stored for 6 months or more, the fuel injection pump linkage needs to be lubricated.Solution
Follow the procedure in this article to lubricate the fuel injection pump linkage.
Remove the fuel shutoff solenoid. Refer to Disassembly and Assembly, "Fuel Shutoff Solenoid - Remove and Install" for the correct procedure.
Spray the fuel control rack with a suitable lubricant spray.
Use a suitable magnet to operate the fuel control rack. The operation of the fuel control rack will disperse the lubricant.Note: If the fuel control rack does not move freely, then the fuel injection pump should be replaced. Refer to Disassembly and Assembly, "Fuel Injection Pump - Remove and Install" for the correct procedure.
Install the fuel shutoff solenoid. Refer to Disassembly and Assembly, "Fuel Shutoff Solenoid - Remove and Install" for the correct procedure.
Record the repair in the Service Information Management System (SIMSi), including the engine/machine serial number and the date of the repair.
