19100-00802 PUMP ASSY, INJECTI Calibration Data

Illustration 1 g06545921
Typical view inside the DEF pump
(1) Internal heater blanket
Illustration 2 g06545997
Typical view of the DEF pump heater blanket
(2) Pump head heater (top)
(3) Positioning blocksAdaptable To:
Do not operate or work on this product unless you have read and understood the instruction and warnings in the relevant Operation and Maintenance Manuals and relevant service literature. Failure to follow the instructions or heed the warnings could result in injury or death. Proper care is your responsibility.
Illustration 3 g06546003
Typical view of the DEF pump identification label
(4) Part number
(5) Serial number
(6) Date code
Table 1
Part Number Description Serial Number Date Code
466-8285 Diesel Exhaust Fluid Pump Gp (12 V) 19357001 19D357
533-2738 Diesel Exhaust Fluid Pump Gp (24 V) 20058030 20D058 Refer to Table 1 for the effective serial number and date code of the improved heater blanket. Refer to Illustration 3 for the location of the DEF pump identification label.
