Information pump assy, injecti Denso
Product
Fuel Injection Pump
Vehicle engine
COASTER 1HZ
Engine
1HZ
Serial start-end
9108--9208
Info
Injector Nozzle
093500-3650
Manufacture:
22100-17120 TOYOTA
Dim 1
3.2-3.4
Dim 2
5.8-6.0
Dim 3
0.19-0.39
Dim 4
Dim 5
Dim 6
Information
Injector nozzle:
0935003650
KIT List:
Part name
Kit1
Kit2
Cross reference number
Part num
Firm num
Firm
Name
0960006370
22100-17120
TOYOTA
PUMP ASSY, INJECTI
Information:
There are many other diesel fuel specifications published by governments and technical societies. Those diesel fuel specifications usually do not contain all of the parameters addressed by Caterpillar in this specification. To assure optimum engine performance, a complete fuel analysis should be obtained prior to engine operation. The fuel analysis should include all of the properties listed in the Caterpillar Distillate Diesel Fuel Specifications chart. If a particular fuel does not meet the minimum Caterpillar requirements, the engine could exhibit excessive fuel system wear, fuel system failure, or excessive engine wear caused by deposits or corrosion.0.05 Percent Sulfur Diesel Fuel
In the USA, 0.05 percent sulfur diesel fuel has been used in all on-highway diesel truck engines since January 1, 1994. This low sulfur fuel was mandated as a means of directly reducing particulate emissions from diesel truck engines. This low sulfur fuel will also be used in Caterpillar commercial diesel engines where low emissions are required and where supply sources provide this type of fuel. Caterpillar has not seen any detrimental effects with 0.05 percent sulfur fuel in Caterpillar commercial diesel engines.
Heavy Fuel Oil (HFO), Residual fuel, or Blended fuel must NOT be used in Caterpillar diesel engines (except in certain 3600 Series HFO engines). Severe component wear and component failures will result if HFO type fuels are used.
In the USA, 0.05 percent sulfur diesel fuel has been used in all on-highway diesel truck engines since January 1, 1994. This low sulfur fuel was mandated as a means of directly reducing particulate emissions from diesel truck engines. This low sulfur fuel will also be used in Caterpillar commercial diesel engines where low emissions are required and where supply sources provide this type of fuel. Caterpillar has not seen any detrimental effects with 0.05 percent sulfur fuel in Caterpillar commercial diesel engines.
Heavy Fuel Oil (HFO), Residual fuel, or Blended fuel must NOT be used in Caterpillar diesel engines (except in certain 3600 Series HFO engines). Severe component wear and component failures will result if HFO type fuels are used.
