Information pump assy, injecti Denso
Product
Fuel Injection Pump
Vehicle engine
DYNA 3B
Engine
3B
Serial start-end
8805-
Info
Injector Nozzle
093500-2480
Manufacture:
22100-58660 TOYOTA
Dim 1
3.2-3.4
Dim 2
5.3-5.5
Dim 3
0.55-0.75
Dim 4
Dim 5
Dim 6
Information
Injector nozzle:
0935002480
KIT List:
Part name
Kit1
Kit2
Components :
Scheme #.#:
№
Qty
Part num
Name
Remarks
Manufacture num
000
[01]
09600-05340
PUMP ASSY, INJECTI
22100-58660
TOYOTA
Include in ##:
09600-05340
as PUMP ASSY, INJECTI
Cross reference number
Part num
Firm num
Firm
Name
09600-05340
22100-5866
PUMP ASSY, INJECTI
0960005340
22100-58660
TOYOTA
PUMP ASSY, INJECTI
Information:
CATERPILLAR REMAN ANNOUNCES AN APPEARANCE CHANGE TO CERTAIN ELECTRONIC UNIT FUEL INJECTORS
Announcement
The Caterpillar Reman Products Group announces new positioning of the trim code, serial number, and part number laser marking on certain electronic unit injectors. This new positioning will allow the information to be read without removing the injector from the cylinder head. Validation tests confirm the change will not alter quality, reliability, fit, or performance.
Previously, the laser marking was etched on the tappet surface. With this change, the laser marking has been moved to the side of the solenoid. Please note, all identifying information for a Reman injector (trim code, serial number, part number) will appear together in one laser marking as shown below. A list of affected part numbers follows on the next page.
Figure 1: New laser marking location
Figure 2: Close-up view of new laser marking location
Effective immediately, this appearance change will affect the following part numbers:
Reman Part New Equivalent Engine Sales Model
10R0954 2113021 3406E
10R7232 2530619 3406E
10R0959 2113027 3406E, 3456
10R0955 2113025 3406E, 3456, C-15
10R0956 2113022 3406E, C-15
10R8501 2113023 3406E, C-15, C-16
10R0724 2113026 3406E, C-18
10R8502 2113024 3456
10R1305 2490707 C11
10R3147 2490712 C11
10R1274 2394908 C13
10R2977 2490708 C13
10R3071 2490697 C13
10R3262 2490713 C13
10R7236 2490705 C13
10R3262
