Information pump assy, injecti Denso
Product
Fuel Injection Pump
Vehicle engine
INDUSTRIAL RT110
Engine
RT110
Serial start-end
0208-
Info
Injector Nozzle
093500-1930
Injector nozzle:
0935001930
Components :
Scheme #.#:
№
Qty
Part num
Name
Remarks
Manufacture num
000
[01]
09450-08000
PUMP ASSY, INJECTI
PFR1M
1T041-51011
KUBOTA
Include in ##:
09450-08000
as PUMP ASSY, INJECTI
Cross reference number
Part num
Firm num
Firm
Name
09450-08000
1T041-5101
PUMP ASSY, INJECTI
0945008000
1T041-51011
KUBOTA
PUMP ASSY, INJECTI
Information:
POSITIONING PIN BEARING
MARKS FOR TIGHTENING CONNECTING ROD BOLTS(1) Bore in connecting rod for piston pin bearing ... 2.1825 .0005 in.(55.436 0.013 mm) Tight fit between connecting rod eye and piston pin bearing ... .002 to .004 in.(0.05 to 0.10 mm) Connecting rod must be heated for installation of piston pin bearing. Do not use a torch.Heat connecting rod to temperature of ... 350 to 500° F (177 to 260° C) Piston pin bearing junction must be assembled within either area "A" (90 10° from the centerline through the connecting rod bores) as shown.(2) Bore in connecting rod for bearing with nuts tight to specifications (6) ... 4.0748 .0005 in.(103.500 0.013 mm)(3) Distance between center of bearings ... 10.300 .002 in.(261.62 0.05 mm)(4) Bore in bearing for piston pin (new) ... 2.0012 .0003 in.(50.830 0.008 mm) Diameter of piston pin (new) ... 1.9998 .0002 in.(50.795 0.005
