Information pump assy, injecti Denso
Product
Fuel Injection Pump
Vehicle engine
INDUSTRIAL S4L2
Engine
S4L2
Serial start-end
0012-
Info
Injector Nozzle
093500-3840
Injector nozzle:
0935003840
Components :
Scheme #.#:
№
Qty
Part num
Name
Remarks
Manufacture num
000
[01]
09450-07850
PUMP ASSY, INJECTI
PFR4M
Include in ##:
09450-07850
as PUMP ASSY, INJECTI
Cross reference number
Part num
Firm num
Firm
Name
09450-07850
PUMP ASSY, INJECTI
Information:
(6) Depth of bore in head for valve seat insert ... .512 .015 in.(13.00 0.38 mm)(7) Diameter of valve seat insert for exhaust valve ... 1.6870 .0005 in.(42.850 0.013 mm) Bore in head for valve seat insert for exhaust valve ... 1.684 .001 in.(42.77 0.03 mm)Diameter of valve seat insert for intake valve ... 1.8120 .0005 in.(46.025 0.013 mm)Bore in head for valve seat insert for intake valve ... 1.809 .001 in.(45.95 0.03 mm)(8) Angle of face of intake valve seat insert ... 301/4° 1/2°Angle of face of exhaust valve seat insert ... 451/4° 1/2°(9) Dimension from top of closed valve to face of head: Maximum permissible dimension for intake and exhaust ... .048 in.(1.22 mm)Minimum permissible dimension for intake and exhaust ... .008 in.(0.20 mm)(10) Outside diameter of the face of the valve seat insert: Exhaust seat ... 1.591 .005 in.(40.41 0.13 mm)Intake seat ... 1.734 .005 in.(44.04 0.13 mm)(11) "Use again" thickness of valve lip: Exhaust valve ... .080 in.(2.03 mm)Intake valve ... .099 in.(2.51 mm)
