09300-02100 PUMP ASSY, INJECTI Calibration Data


Rating:
3
Buy PUMP ASSY, INJECTI 09300-02100 genuine, new aftermarket engine parts with delivery

Information pump assy, injecti Denso

Product
Fuel Injection Pump
Vehicle engine
CANTER 4DR51A
Engine
4DR51A
Serial start-end
8611--8709
Info
Injector Nozzle
093500-1830
Injector nozzle: 0935001830

KIT List:

Part name
Kit1
Kit2
Body assy, injecti
Timer assy, automa
Pump assy, fuel fe
Governor assy, mec

Components :

00.001
PUMP ASSY, INJECTI
A4,RU
01.002
BODY ASSY, INJECTI
A4:DRIV.16.8
01.003
TIMER ASSY, AUTOMA
SCZ
01.004
PUMP ASSY, FUEL FE
KS
01.005
GOVERNOR ASSY, MEC
RU -8707
01.005
GOVERNOR ASSY, MEC
9011-
01.005
GOVERNOR ASSY, MEC
8707--9011

Scheme #.#:

Qty
Part num
Name
Remarks
Manufacture num
000
[01]
09300-02100
PUMP ASSY, INJECTI
A4,RU
ME006206 MITSUBISHI
003
[01]
BODY ASSY, INJECTI
A4:DRIV.16.8
ME006161 MITSUBISHI
004
[01]
GOVERNOR ASSY, MEC
RU
ME703374 MITSUBISHI
005
[01]
PUMP ASSY, FUEL FE
KS
ME016021 MITSUBISHI
006
[01]
TIMER ASSY, AUTOMA
SCZ
ME703026 MITSUBISHI
007
[01]
COVER SUB-ASSY, TI
ME006130 MITSUBISHI
008
[01]
O-RING
ID62.5
MH035501 MITSUBISHI
009
[04]
WASHER, STEEL PLAT
FOR M10
MH005068 MITSUBISHI
012
[01]
KEY, WOODRUFF
ME703361 MITSUBISHI
013
[01]
WASHER, SPRING
T2.5
ME008373 MITSUBISHI
014
[01]
NUT, TIMER ROUND
ME703450 MITSUBISHI
015
[01]
COVER, CONTROL RAC
ME702034 MITSUBISHI
016
[06]
BOLT, W/WASHER
M6,L14
ME703359 MITSUBISHI
020
[02]
CAP
FOR MAX.SPEED
ME035845 MITSUBISHI

Include in ##:

09300-02100 as PUMP ASSY, INJECTI

Cross reference number



Part num
Firm num
Firm
Name
09300-02100
ME006206
PUMP ASSY, INJECTI
0930002100
ME006206
MITSUBISHI
PUMP ASSY, INJECTI

Test Calibration Data:
