09300-01880 PUMP ASSY, INJECTI Calibration Data


Rating:
65
Buy PUMP ASSY, INJECTI 09300-01880 genuine, new aftermarket engine parts with delivery

Information pump assy, injecti Denso

Product
Fuel Injection Pump
Vehicle engine
CANTER 4D30A
Engine
4D30A
Serial start-end
8604--9805
Info
Injector Nozzle
093500-2470
Injector nozzle: 0935002470

KIT List:

Part name
Kit1
Kit2
Body assy, injecti
Governor assy, mec
Timer assy, automa
Pump assy, fuel fe
Pump assy, fuel fe

Components :

00.001
PUMP ASSY, INJECTI
A4,R801 -9308
00.001
PUMP ASSY, INJECTI
A4,R801 9309-
01.002
BODY ASSY, INJECTI
A4:DRIV.16.8
01.003
GOVERNOR ASSY, MEC
R801
02.004
COVER ASSY, GOVERN
02.005
COVER ASSY, GOVERN
01.006
TIMER ASSY, AUTOMA
SCZ
01.007
PUMP ASSY, FUEL FE
KS
01.008
PUMP ASSY, FUEL FE
KS

Scheme #.#:

Qty
Part num
Name
Remarks
Manufacture num
000
[01]
PUMP ASSY, INJECTI
A4,R801 -9308
000
[01]
PUMP ASSY, INJECTI
A4,R801 9309-
003
[01]
BODY ASSY, INJECTI
A4
004
[01]
GOVERNOR ASSY, MEC
R801
005
[01]
PUMP ASSY, FUEL FE
KS -9508
005
[01]
PUMP ASSY, FUEL FE
KS22 9509-
006
[01]
TIMER ASSY, AUTOMA
SCZ
007
[01]
COVER SUB-ASSY, TI
008
[01]
O-RING
009
[04]
WASHER, STEEL PLAT
FOR M10
012
[01]
KEY, WOODRUFF
013
[01]
WASHER, SPRING
T2.5
014
[01]
NUT, TIMER ROUND
-8909
014
[01]
NUT, TIMER ROUND
8909-
015
[01]
COVER, CONTROL RAC
016
[01]
BOLT, HEXAGON
M8,L18
019
[04]
BOLT, W/WASHER
M6,L16
020
[01]
BOLT, W/WASHER
M6,L11.5
022
[01]
CAP

Cross reference number



Part num
Firm num
Firm
Name
09300-01880

PUMP ASSY, INJECTI

Test Calibration Data:

0930001880 ME016709




Information:

Start By:a. remove cylinder headb. remove oil panc. remove cooling jets 1. Remove two rod cap bolts (1) from each rod. Remove rod caps (2).2. Using a soft hammer tape rod (3) away from crankshaft and remove bearing half (4). When removing cylinder pack, watch the rod and prevent it from catching on the block bore as it comes out.3. Install tooling (A) and remove cylinder pack (5). 4. Remove cylinder liner seal (6) at the base of the spacer block. 5. Remove the remainder of tooling (A) from cylinder pack (5) and then remove the rod and piston from the cylinder liner. The following steps are for the installation of the cylinder pack.6. Install a new cylinder liner seal, lubricate the seal with engine oil. Some engines use pistons which have the word "FRONT" stamped on the crown of the piston. Make sure the word "FRONT" is toward the front of the engine when the piston is installed. The etched number on the connecting rod must be on the right side and must be installed in the corresponding cylinder. 9U-5839 Liquid Gasket Material is applied to the cylinder liners in the area shown in the illustration. The liquid gasket material helps prevent oil leaks from between the cylinder block and spacer block. DO NOT apply any 9U-5839 Liquid Gasket Material between the engine spacer block and the cylinder block surfaces. Using excessive amounts of liquid gasket material on the liner flange seat can cause oil leaks due to distortion of the O-ring seals between the spacer block and cylinder block.7. Lubricate the lower portion of the cylinder liner with engine oil. Be sure the corresponding crankshaft throw is at bottom center. Position cylinder pack (5) and guide rod (3) into place. Use tooling (B) and press cylinder pack (5) into place.8. With rod (3) in this position, install the upper half of rod bearing (4). Be sure the bearing tab properly engages the slot in the connecting rod. Lubricate the bearing surface with engine oil and tap the piston down with a rubber mallet until the rod and bearing contacts the crankshaft.9. With rod cap bearing in place and oiled, install rod cap (2). Lubricate rod bolts (1) with 2P2506 Thread Lubricant. Install rod bolts (1) and torque to 130 7 N m (95 5 lb.ft.). Mark each bolt head and then tighten each bolt an additional 60 5° (1/6 turn).End By:a. install cooling jets.b. install oil pan.c. install cylinder head.
