09300-01502 PUMP ASSY, INJECTI Calibration Data


Rating:
4
Buy PUMP ASSY, INJECTI 09300-01502 genuine, new aftermarket engine parts with delivery

Information pump assy, injecti Denso

Components :

00.001
PUMP ASSY, INJECTI
A4,RU
01.002
BODY ASSY, INJECTI
A4:DRIV.16.8
01.003
TIMER ASSY, AUTOMA
SCZ
01.004
PUMP ASSY, FUEL FE
KS
01.005
PUMP ASSY, FUEL FE
KS
01.006
GOVERNOR ASSY, MEC
RU

Scheme #.#:

Qty
Part num
Name
Remarks
Manufacture num
000
[01]
09300-01502
PUMP ASSY, INJECTI
A4,RU
ME016224 MITSUBISHI
003
[01]
BODY ASSY, INJECTI
A4:DRIV.16.8
ME703044 MITSUBISHI
004
[01]
GOVERNOR ASSY, MEC
RU
ME703045 MITSUBISHI
005
[01]
PUMP ASSY, FUEL FE
KS -9508
ME016021 MITSUBISHI
005
[01]
PUMP ASSY, FUEL FE
KS 9509-
ME703037 MITSUBISHI
007
[01]
KEY, WOODRUFF
ME703361 MITSUBISHI
008
[01]
WASHER, SPRING
T2.5
ME008373 MITSUBISHI
009
[01]
NUT, TIMER ROUND
-8909
ME022426 MITSUBISHI
009
[01]
NUT, TIMER ROUND
8909-
ME703450 MITSUBISHI
010
[01]
COVER, CONTROL RAC
ME022416 MITSUBISHI
013
[01]
WASHER, PLATE
M6,T1.5
ME703364 MITSUBISHI
014
[06]
BOLT, W/WASHER
M6,L14
ME703359 MITSUBISHI
015
[02]
CAP
FOR MAX.SPEED
ME035845 MITSUBISHI
016
[01]
TIMER ASSY, AUTOMA
SCZ
ME016163 MITSUBISHI
017
[01]
COVER SUB-ASSY, TI
ME016070 MITSUBISHI
018
[01]
O-RING
ID62.5
MH035501 MITSUBISHI
019
[04]
WASHER, STEEL PLAT
FOR M10
MH005068 MITSUBISHI
020
[04]
WASHER, SPRING
M10
MC327716 MITSUBISHI
021
[04]
NUT, HEXAGON
M10
MF430122 MITSUBISHI
030
[01]
ACTUATOR SET, IDLE
ME016169 MITSUBISHI

Include in ##:

09300-01502 as PUMP ASSY, INJECTI

Cross reference number



Part num
Firm num
Firm
Name
09300-01502
ME016224
PUMP ASSY, INJECTI

Test Calibration Data:

0930001500 ME016224
0930001502




Information:

SUBJECT: System Malfunctions Related To The Injection Actuation Pressure Sensors In Excavators, Wheel Loaders, Engines, Track-Type Tractors and Track Loaders
PROBLEM:
The Injection Actuation Pressure (IAP) sensors are being replaced on machine applications with C7/3126 engines. Some C9 engine models are also affected. The system event code 164-11 or 164-02 leads the technician to replace the sensor. Many of these sensors are no fault found. The result of these failures is loss of production due to unscheduled downtime.
SOLUTION:
Follow current troubleshooting guidelines for highway trucks to troubleshoot the part causing the failure. This will aid the technician in finding the correct part causing the failure. Report any troubleshooting guidelines errors using the feedback function in the Service Information System (SIS Web).
COPYRIGHT 2005 CATERPILLAR
ALL RIGHTS RESERVED
