Information pump assy, injecti Denso
Product
Fuel Injection Pump
Vehicle engine
INDUSTRIAL S4Q2
Engine
S4Q2
Serial start-end
0003-
Info
Injector Nozzle
093500-5480
Injector nozzle:
0935005480
KIT List:
Part name
Kit1
Kit2
Components :
Scheme #.#:
№
Qty
Part num
Name
Remarks
Manufacture num
000
[01]
09200-04510
PUMP ASSY, INJECTI
A4,RSV
Include in ##:
09200-04510
as PUMP ASSY, INJECTI
Cross reference number
Part num
Firm num
Firm
Name
09200-04510
PUMP ASSY, INJECTI
Information:
Problem
The lift adjusting screw may break in certain 7E3969 1W5829, 4W8483, and 7W3710 Fuel Injection Nozzles with date codes of A9 thru M9, and A0 thru L0. If the adjusting screw breaks the adjustment screw in the nozzle can vibrate toward the fuel shutoff position which can result in the following symptoms:
A) Low Horsepower. The affected engine may not reach rated rpm. The engine does not emit any excessive black smoke. The engine may or may not have a detectable miss.B) Low Horsepower. The affected engine may not reach the rated rpm. The engine may emit heavy black smoke.C) Low Idle Misfire. Some engines run at rated speed but have a miss when idling.Affected Product
Model & Identification Number
3208 (30A3876-4565; 90N72172-73198; 75V10138-10420; 62W58913-Up; 01Z19535-22859; 03Z9391-10398; 51Z79496-80434)
Parts Needed
8* - 7E3969 Nozzle8* - 9L6969 Nozzle8* - 9N3299 Nozzle8* - 1W5829 Nozzle8* - 4W1819 Nozzle8* - 4W8483 Nozzle8* - 7W3710 Nozzle*Refer to your engine arrangement for the correct part number.Action Required
Parts Stock
Inspect all 7E3969, 9L6969, 9N3299, 1W5829, 4W1819, 4W8483, and 7W3710, Fuel Injection Nozzles for the date code as shown in the illustration. If date codes of A9, B9, C9, D9, E9, F9, G9, H9, I9, J9, K9, L9, M9, A0, B0, C0, D0, E0, F0, G0, H0, I0, J0, K0, or L0 are on the nozzles, remove the nozzles from parts stock.
Fuel Injection Nozzle Date Codes If the part number or date code is difficult to read, apply white paint to the area and carefully remove any excess.
Affected Product
If possible, isolate the cylinder(s) with a failed nozzle by loosening the fuel line nuts. The nozzle cap(s) may be removed to check for a broken lift adjustment screw.
Check the date code on the replacement nozzles before installing them. The date code on the flat of the nozzle nut must be M0, A1, B1, C1, or higher. Some nozzles will have a date code above the part number and a second date code on another flat of the nozzle nut. The second date code will continue two letters and a number. The first letter will always be an "R". The second letter is for the month "A-M". The number will be 0 for 1990 or 1 for 1991.
Any nozzle with a date code between A9 and M9 or A0 and L0 without the second date code should not be used.
On a twin engine marine installation, install new nozzles in both engines.
Service Claim Allowances
Parts Stock
Submit one claim for all 7E3969, 9L6969, 9N3299, 1W5829, 4W1819, 4W8483, and 7W3710, Fuel Injection Nozzles removed from parts stock.
Affected Product
This is a 5-hour job.
On a twin engine marine installation, a separate claim must be filed for the second engine.
Parts Disposition
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
The lift adjusting screw may break in certain 7E3969 1W5829, 4W8483, and 7W3710 Fuel Injection Nozzles with date codes of A9 thru M9, and A0 thru L0. If the adjusting screw breaks the adjustment screw in the nozzle can vibrate toward the fuel shutoff position which can result in the following symptoms:
A) Low Horsepower. The affected engine may not reach rated rpm. The engine does not emit any excessive black smoke. The engine may or may not have a detectable miss.B) Low Horsepower. The affected engine may not reach the rated rpm. The engine may emit heavy black smoke.C) Low Idle Misfire. Some engines run at rated speed but have a miss when idling.Affected Product
Model & Identification Number
3208 (30A3876-4565; 90N72172-73198; 75V10138-10420; 62W58913-Up; 01Z19535-22859; 03Z9391-10398; 51Z79496-80434)
