19080-01750 GOVERNOR ASSY, MEC Denso Cross

Tightening Procedure For Main Bearings(8) Torque for the bolts that hold the caps for the main bearings: Install the main bearing caps with the marks (arrow) toward the front of the engine. Install each cap in the correct position by putting the number stamped on the bottom of the cap toward the corresponding number cast on left side of the cylinder block at the pan rail.a. Put 2P2506 Thread Lubricant on the threads of the bolts.b. Tighten the bolts first on the bearing tab side of the cap to ... 260 14 N m (190 10 lb ft)c. Tighten the bolts on the opposite side to ... 260 14 N m (190 10 lb ft)d. Put a mark on each bolt and cap.e. Tighten the bolts on the opposite side, from the mark ... 120 5°f. Tighten the bolts on the bearing tab side of the cap, from the mark ... 120 5°(9) Dimension (new) from centerline of crankshaft bearing bore to bottom of block (pan rails) ... 165.10 0.10 mm (6.500 .004 in)
View From Right Side Of Cylinder Block(10) Put 5P3414 Pipe Sealant on threads of plugs before installation in the cylinder block.(11) Torque for bolts holding oil jet cooling tubes ... 30 7 N m (22 5 lb ft) Minimum permissible clearance between piston and oil jet cooling tube ... 0.64 mm (.025 in)
