09507-10071 CONNECTOR, FUEL OU Denso Cross

(4) Thickness of cylinder head (new) ... 112.78 0.25 mm (4.440 .010 in) Minimum permissible thickness of cylinder head ... 111.51 mm (4.390 in)(5) Torque for six studs that hold fuel line adapter locks ... 30 5 N m (22 4 lb ft) Flatness of the cylinder head should be within 0.13 mm (.005 in) total, and a maximum of 0.03 mm (.001 in) for any 76.2 mm (3.00 in) span.
When the cylinder head is installed on an engine with a water cooled exhaust manifold, plug (A) MUST be removed to prevent damage to the water cooled exhaust manifold. If the engine has a dry exhaust manifold, plug (A) MUST NOT be removed.
