09649-00081 COMPENSATOR SUB-AS Denso Cross


Rating:
8
Buy COMPENSATOR SUB-AS 09649-00081 genuine, new aftermarket engine parts with delivery

Information compensator sub-as Denso

Scheme #.#:

Qty
Part num
Name
Remarks
Manufacture num
000
[01]
09649-00081
COMPENSATOR SUB-AS
001
[01]
COVER SUB-ASSY, GO
002
[01]
COVER SUB-ASSY, GO
22703-54262 TOYOTA
003
[01]
STOPPER, TIMER SLI
22658-64518 TOYOTA
004
[01]
R0D, PUSH
22321-54470 TOYOTA
005
[01]
BUSHING, GUIDE
22348-64360 TOYOTA
006
[01]
DIAPHRAGM
22542-54260 TOYOTA
007
[01]
SHEET, PLUNGER SPR
22143-54260 TOYOTA
008
[01]
BUSHING, GUIDE
22348-54490 TOYOTA
009
[01]
NUT, HEXAGON
M18
90099-05156 TOYOTA
010
[01]
CLIP, TIMER
22656-54490 TOYOTA
011
[01]
PIN, LEVER CONECTI
22338-54120 TOYOTA
012
[01]
BUSHING, GUIDE
22348-54121 TOYOTA
013
[01]
NUT, GOVERNOR SHAF
22722-54120 TOYOTA
014
[01]
WASHER, COPPER PLA
T1
90099-01473 TOYOTA
015
[01]
O-RING
ID 4
22193-55031 TOYOTA
016
[01]
PIN, LEVER SUPPORT
22526-54120 TOYOTA
017
[01]
LEVER SUB-ASSY, CO
-9805
22308-54120 TOYOTA
017
[01]
LEVER SUB-ASSY, CO
9806-
018
[02]
WASHER, DRAIN SCRE
-9408
22378-76010 TOYOTA
018
[02]
GASKET, DELIVERY V
9408-
22149-6D450 TOYOTA
019
[04]
BOLT, SOCKET
M6,L14
22395-54263 TOYOTA
020
[02]
BOLT, GOVERNOR LIN
22739-54120 TOYOTA
021
[01]
O-RING
ID10
22193-54561 TOYOTA
022
[01]
NUT, HEXAGON
M8 -0602
90099-05181 TOYOTA
022
[01]
NUT, HEXAGON
M8 0602-
90099-05252 TOYOTA
023
[01]
WASHER, PLATE
T1
90093-00802 TOYOTA
024
[01]
NUT, HEXAGON
90092-20608 TOYOTA
025
[01]
SCREW SUB-ASSY, OV
W/FILTER
22160-54262 TOYOTA
026
[01]
WASHER, AIR BLEEDE
-9704
22119-77020 TOYOTA
026
[01]
GASKET, DELIVERY V
9704-
22149-54800 TOYOTA
027
[01]
PLUG, SCREW
22129-54120 TOYOTA
028
[1C]
SPRING, BOOST COMP
L19.8
22546-54260 TOYOTA
028
[1C]
SPRING, BOOST COMP
L19.6
22546-54261 TOYOTA
030
[01]
WASHER, THRUST
22549-17140 TOYOTA

Include in ##:

09600-01920 as COMPENSATOR SUB-AS

Cross reference number



Part num
Firm num
Firm
Name
09649-00081

COMPENSATOR SUB-AS




Information:

Start By:a. remove valve cover 1. Remove four bolts (1) that hold each rocker arm assembly in position. Remove the rocker arm assemblies from the engine.2. Put identification marks on all push rods as to their location in the engine. Remove the push rods from the engine. 3. Disassemble the rocker arm assemblies as follows: a. Remove the pin and rocker arm mounts (2). Remove the two rocker arm assemblies and the unit injector arm assembly from the shaft assembly.b. Remove the nut and valve adjusting screw (3) from each rocker arm.c. Remove arm button (7), retaining ring (6) and the arm socket from the unit injector arm.d. Loosen the nut, and remove injection adjusting screw (4) from the unit injector arm.e. Remove sleeve bearing (5) from the unit injector arm. The following steps are for the installation of the rocker arm assemblies and push rods.4. Be sure all parts of the rocker arm assemblies are clean.5. Assemble the rocker arm assemblies as follows: a. Install sleeve bearing (5) in the unit injector arm with Tool (A).b. Install injection adjusting screw (4) and the nut in the unit injector arm.c. Install the arm socket, retaining ring (6) and arm button (7) in the unit injector arm.d. Install valve adjusting screw (3) and the nut in each rocker arm.e. Put the rocker arm assemblies and the unit injector arm assembly in position on the shaft assembly. Install two rocker arm mounts (2) and the pins that hold them.6. Apply clean engine oil to the push rods, and install them in their original locations in the engine. Be sure the push rods are seated in the lifter arm assemblies.7. Loosen all adjusting screws in the rocker arm assemblies. Position the rocker arm assemblies on the cylinder head assembly, and install bolts (1) that hold them in position.8. Adjust the fuel timing and the valve lash. See the topics "Fuel Timing" & "Valve Lash" in the 3114 & 3116 Diesel truck Engines Systems Operation & Testing & Adjusting module, Form No. SENR6437.End By:a. install valve cover
